Lumicam

Overview

When delivering predictable clinical results depends on raising skin temperature, eliminate the guesswork with the LumiCam thermal imaging system. LumiCam is the most advanced and versatile diagnostic tool available for a range of aesthetic procedures. Powered by High Definition Thermal Imaging, or HDTI, the system employs the ToughCam Pro and provides an FDA approved, mobile solution for real time temperature feedback and thermal mapping of the treatment area, displaying it in high definition on an integrated 19-inch monitor.

TriPollar-LumiCamHD combines the latest innovation in radio-frequency technology with the most advanced thermal imaging technology on the market, ensuring accuracy and clarity with every anti-aging, body contouring and cellulite treatment. Thermal imaging and real time temperature feedback allow the therapeutic window to be reached safely and effectively while ensuring that there is homogenous delivery of energy.

Features

LumiCam Features:



  • Real time temperature feedback
  • High Definition Thermal Imaging on 19in mobile display
  • Visual validation for the patient
  • 3D rendering

System Specifications:



  • Resolution – 160 x 120
  • Detector Type – Microbolmeter
  • Wave Length – Long Wave
  • Spectral Range – 7 .14 um
  • Field of View – 21.1” x 15.8”
  • Field of View – 1.3 mrad
  • Minimum Focus Distance – 6” (152.4mm) to infinity
  • Temperature Range – 20 C to 800 C (-4 F to 1112 F) optional 1000 C
  • Image Refresh Frequency – 60Hz (NTSC) or 50Hz (PAL)
  • Display – High- resolution color 2.8” (71.12 mm) LCD
  • Interfaces – USB
  • Power – 10-14V power supply provided
  • Battery – Rechargeable Li-ion
  • Operating Temperature – -20 C to 50 C (-4 F to 122 F)
  • Dimensions – 9.5”L x 3”W x 2.5”H
  • Weight – 19 oz.
  • Laser Included – Yes
  • Visible Camera Included – Yes
  • Auto-tracking Included – Yes
  • Temperature Measurement Points


Display Stand Dimensions:



  • Base – 24” diameter
  • Min. Height – 46”
  • Max. Height – 68”
  • Weight – 13 lbs.
